Cabinet-type Capacitor Bank
Cabinet-type capacitor bank integrates capacitors, reactors, arresters in a cabinet. For reactive compensation in 6-35kV systems. Suitable for indoor substations, industrial and mining enterprises.
-
Cabinet Integration
-
Streamlined Installation
-
Engineered to Adapt
-
Environmental Tolerance
Product Highlights
Cabinet Integration
Highly integrates capacitors, reactors, and arresters in a compact cabinet, saving space with IP3X protection rating.
Streamlined Installation
Complete cabinet transport, ready for operation after on-site wiring. All maintenance and operations can be performed from the front.
Engineered to Adapt
Suitable for 220kV and below substations, power plants, and large industrial enterprises. Automatically adjusts bus voltage.
Environmental Tolerance
Operates stably indoors at -25℃ to +55℃, altitude up to 2000m, and relative humidity ≤95% (daily average). For installations above 2000m, please specify when ordering.
Technical Specification
System Rated Voltage
6kV ~ 35kV
Rated Frequency
50Hz / 60Hz
Rated Capacity
150kvar ~ 30000kvar
Protection Rating
IP3X
Ambient Temperature
-25℃ ~ +55℃
